PULSAR TELOS LRF XP50 THERMAL MONOCULAR IN STOCK

Email
IN STORE
77492.tag.0
77492.tag.1
77492.tag.2
77492.tag.3
77492.tag.4
77492.tag.5
Variant price modifier:
$5,899.00
$5,399.00
$-500.00
Price / kg:
77492.tag.0
77492.tag.1
77492.tag.2
77492.tag.3
77492.tag.4
77492.tag.5
Description

Model

LRF XP50

SKU

77492

Microbolometer



Type

uncooled

Resolution, Pixels

640x480

Pixel Pitch, µm

17

NETD, mK

< 18

Frame Rate, Hz

50

Optical Characteristics



Optical Magnification, x

2.5

Smooth Digital Zoom

2.5 -10

Digital Zoom, x

x1 - x4

Lens Focus, mm

50

Relative Aperture, D/f'

1.0

Minimum Focus Distance, m/y

5 / 5.5

Exit Pupil Diameter, mm/inch

4 / 0.16

Angular Field of View (Horizontal x Vertical), degree

12.4x9.3

Linear Field of View, m at 100 m

21.8

Eyepiece Focus Range, Dioptre

+4 / -5

Detection Distance for Deer-Sized Objects, m/y

1800 / 1969

Display



Type

AMOLED

Resolution, Pixels

1024x768

Operational Characteristics



Power Supply, V

3 - 4.2

Battery Type/Capacity/Nominal Output Voltage

LPS7i Li-ion Battery Pack / 6400 mAh / DC 3.7 V

External Power Supply

5 V, 9 V (USB Type-C)

Battery Run Time at t=22°C, hours*

8.5

Degree of Protection, IP Code (IEC60529)

IPX7

Operating Temperature Range, °C / °F

-25 … +40 / -13 – +104

Dimensions, mm/inch

238x72x90 / 9.37x2.83x3.54

Weight (with battery), kg/oz

0.72 / 25.4

Video Recorder



Photo/Video Resolution, Pixels

1024x768

Video/Photo Format

.mp4 / .jpg

Built-in Memory

64 GB

Wi-Fi Channel**



Frequency

2.4/5 GHz

Standard

IEEE 802.11 b/g/n/ac

Characteristics of the Rangefinder



Wavelength, nm

905

Measurement Range, m/y***

1000/1094

Measurement Accuracy, m

1
